- Unrivaled power handling
- Dual voice coil design
- Die-cast, vented alumium frame
- Composite paper full-edge subwoofer dust cap and cone
- NBR(nitrile butadiene rubber) surround
- Progressive spider
Color: Black
Features
Unrivaled power handling
The JBL Arena 12 is engineered to product uncompromising, mammoth base from an amplifier capable of delivering up to 2,400 Watts (800 Watts RMS) of power.
Dual voice coil design
The Arena 12's powerful dual 2.5-inch voice coils are each suspended in a separate magnetic gap. At low power, both coils drive the cone, cancelling any nonlinearities. As power increases and one coil rides out of its gap, the other coil still applies force to the cone.
Die-cast, vented alumium frame
The Arena's aluminum frame features significant venting and heatsink fins for added power handling, and rigid construction to keep critical voice coil components in perfect alignment.
Composite paper full-edge subwoofer dust cap and cone
Composite paper's combination of light weight and rigidity make it the ideal cone material to move a large amount of air without flex or distortion.
NBR(nitrile butadiene rubber) surround
The Arena utilizes a single piece NBR surround seal between the front and back of the woofer. NBR is environmentally stable, meaning you get the same elite performance from the Arena during Summer and Winter.
Progressive spider
The Arena's progressive spider ensures restoring force to the cone, resulting a more musical experience from the subwoofer even in the highest excursion conditions.
Specs & Downloads
Item#: JBLSUBAR12AM
EAN: 6925281992308
General Specifications
- Power Handling(Peak)
- 2400 Watts
- Power Handling(RMS)
- 800 Watts
- Sensitivity(2.83V/1m)
- 87dB
- Frequency Response
- 22 - 200Hz
- Impedance
- SSI Switch 2 or 4 ohms that is patented Selectable Smart Impedance (SSI) technology
- 1 x 12” subwoofer
- 1 x Owner Manual
- 1 x Screw Bag
- 1 x sealed tape
- 2 x JBL stickers
